LED BUS Destination Sign 19.2 × 57.6 cm – P3 Full Color RGB

LED BUS Destination Sign 19.2 × 57.6 cm – P3 Full Color RGB

Programmable route and stop display for minibuses, buses and coaches

Product description

The LED BUS destination sign 19.2 × 57.6 cm is a programmable display designed to show route numbers, travel directions, place names, stop names and information messages in minibuses, buses, coaches and other passenger transport vehicles. The matrix uses LED SMD Full Color RGB technology, allowing content to be displayed in full color.

The P3 pixel pitch means a 3 mm distance between pixels. With an active area of 192 × 576 mm, the display achieves a resolution of 64 × 192 pixels, for a total of 12,288 pixels. The fine pixel pitch improves text readability and allows more information to be presented on a compact surface.

Programmable LED BUS P3 destination sign 19.2 × 57.6 cm designed to display route numbers, travel directions, place names, stops and messages in minibuses, buses and coaches. The Full Color RGB matrix with a resolution of 64 × 192 px provides good content readability despite the compact size of the device. Wireless program transfer, smartphone operation and an IR remote control make everyday operation easier for the driver.

The P3 pixel pitch, i.e. a 3 mm distance between pixels, provides a resolution of 64 × 192 pixels on an active area of just 192 × 576 mm. In total, the matrix offers 12,288 pixels, making it well suited to applications that require readable text and a larger amount of information on a relatively compact surface. The fine P3 pixel pitch is particularly beneficial where the viewer observes the screen from a short distance.

The matrix uses LED SMD Full Color RGB technology with SMD2020 LEDs. A brightness of at least 600 cd/m² and a refresh rate of at least 3840 Hz help provide a stable and readable image during operation inside the vehicle. The screen is built from 3 LED modules measuring 192 × 192 mm, each with a resolution of 64 × 64 px.

Content can be prepared in advance on a computer or mobile device and then transferred wirelessly to the built-in controller memory. Once the programs have been saved, the display can operate independently without a permanent connection to a computer. The driver can switch between stored routes, stops and messages using a smartphone as a remote control or the included IR remote control.

The device is designed to be powered from the vehicle electrical system at 12/24 V DC, making it suitable for minibuses, buses, coaches and other passenger transport vehicles. The matrix operating temperature range is -10°C to +50°C.

Key features

• active LED area: 192 × 576 mm (19.2 × 57.6 cm),

• pixel pitch: P3 – 3 mm,

• resolution: 64 × 192 px – 12,288 pixels in total,

• 3 LED modules, each measuring 192 × 192 mm,

• resolution of one module: 64 × 64 px,

• display technology: LED SMD Full Color RGB (SMD2020), 1/32 scan,

• matrix brightness: ≥ 600 cd/m²,

• refresh rate: ≥ 3840 Hz,

• device power supply: 12/24 V DC – designed for the vehicle electrical system,

• wireless transfer of prepared content to the display memory,

• control from a computer and a mobile device such as a smartphone,

• the smartphone can act as a remote control for switching between previously programmed programs,

• IR remote control included – for quick switching between successive stops or messages by the driver.

Technical specifications

Why is P3 pixel pitch a good choice for a BUS destination sign?

With an active display height of 19.2 cm, the P3 pixel pitch provides 64 pixels vertically. Horizontally, 192 pixels are available. This resolution enables clear display of route numbers, stop names, place names, travel directions and short messages without the need for a large enclosure.

A fine pixel pitch is particularly important in a vehicle, where a passenger or a person waiting at a stop often views the display from a short distance.

Key benefits:

• Clear presentation of routes and stops – P3 pixel pitch and 64 × 192 px resolution enable clear display of names, route numbers and messages.

• More information on a compact surface – the active LED area is only 19.2 × 57.6 cm while still offering 12,288 pixels.

• Full RGB color – LED SMD Full Color technology makes it possible to prepare clearer and more visually engaging messages.

• High refresh rate ≥ 3840 Hz – stable image without noticeable flicker during normal viewing.

• Operation without a permanent computer connection – prepared programs are stored in the controller memory and played directly by the display.

• Convenient control while driving – stored programs can be switched using a smartphone or the included IR remote control.

• 12/24 V DC power supply – the device is designed for typical electrical systems used in vehicles.

• Compact modular design – the matrix consists of three 192 × 192 mm LED modules, providing a practical destination-sign format.

Applications:

• minibuses,

• city and regional buses,

• coaches,

• passenger transport vehicles,

• front destination signs,

• side information displays,

• route number display,

• display of direction and destination,

• display of successive stop names,

• passenger information messages,

• technical and special messages,

• technical service run indication.

Functions:

• displaying route numbers,

• displaying travel direction and place names,

• displaying stop names,

• displaying information and special messages,

• displaying content in Full Color RGB technology,

• preparing programs on a computer,

• operation from a mobile device such as a smartphone,

• wireless transfer of prepared programs to the display memory,

• saving multiple pre-prepared programs in the controller memory,

• standalone operation after the content has been saved,

• switching programs using a smartphone,

Content management and programming

Display content is prepared in advance on a computer using the control software. Once editing is complete, the finished program is transferred wirelessly to the LED display memory. The device can then operate independently without a permanent connection to a computer.

Multiple programs can be stored in the display memory, e.g. routes, place names, route numbers, stop names or special messages. Once saved, the driver does not need to edit the content each time – simply select the appropriate pre-prepared program.

Smartphone operation

Content can also be managed from a smartphone. The phone can communicate with the display, transfer prepared data and serve as a convenient remote control for stored programs.

The smartphone can act as a remote control, allowing the driver or operator to switch between successive pre-programmed programs without starting a computer.

IR remote control – included

An IR remote control is also included for day-to-day driver operation. It can be used to switch between pre-programmed stop names, place names, route directions or other messages stored in the display memory.

The driver can therefore operate the display in two ways: with a smartphone used as a remote control or with the included IR remote control.

Example program organization

Driver operation

• Routes, stops and messages are prepared in advance on a computer or mobile device.

• Ready-made programs are transferred wirelessly to the display memory.

• While the vehicle is in service, the display plays the stored content independently.

• The driver switches between successive pre-programmed items using a smartphone or the IR remote control.

• There is no need to connect a computer or recreate content each time during a route.

12/24 V DC power supply

The display is designed to be powered from a vehicle electrical system at 12 V or 24 V DC. This allows the device to be used in minibuses, buses and coaches with a standard 12/24 V vehicle electrical system.

The wiring method, circuit protection and connection point in the vehicle electrical system should be selected according to the configuration of the specific vehicle and the device design.

Possible applications

The display can operate as a front or side destination sign, show the route number and travel direction, successive stop names, passenger messages, route and destination information, as well as technical and special messages.

Summary

The LED BUS P3 Full Color RGB destination sign 19.2 × 57.6 cm offers a resolution of 64 × 192 px, wireless content upload from a computer or smartphone, smartphone remote-control operation and an included IR remote for switching between successive stops. Power supply: 12/24 V DC.
